Connector-Star Can IHS IP C5 (D2601E)

Harness-Family: IP

Color: Black

Gender: MALE

Part Number: 1-1418639-1

Part Description: Not Available

Connector No: D2601E

Option: ~~

Repair Kit Part Number: 68137879AA

Cavity Count: 2

Fig 1: Connector-Star Can Ihs Ip C5 Connector End View
GCWD1016913Courtesy of CHRYSLER
Fig 2: Connector-Star Can Ihs Ip C5 Component Location
GCWD1002036Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D463 OR ~~ CAN C (+) - INTEGRATED CENTER STACK N/A
2 D462 WT ~~ CAN C (-) - INTEGRATED CENTER STACK N/A
(1) Pins not listed are not used for this connector
