Switch-Parking Brake (LHD) (D2269A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 520961-1

Part Description: INSL

Connector No: D2269A

Option: LHD

Repair Kit Part Number: 05019927AA

Cavity Count: 1

Fig 1: Switch-Parking Brake Connector End View (LHD)

Courtesy of CHRYSLER

Fig 2: Switch-Parking Brake Component Location (LHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B25

GY/BK

PARK BRAKE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
