Starter-Eyelet-A (3.0L/3.6L) (D6637A)

Harness-Family: Battery_Positive

Color: ~~

Gender: MALE

Part Number: 7003-2718-02

Part Description: Not Available

Connector No: D6637A

Option: 3.0L/3.6L

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Starter-Eyelet-A Connector End View (3.0L/3.6L)

Courtesy of CHRYSLER

Fig 2: Starter-Eyelet-A Component Location (3.0L/3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
