Speaker-Right Front Door (Premium) (D5909A)

Harness-Family: Door_Front_Right

Color: WHITE

Gender: FEMALE

Part Number: 174463-1

Part Description:070 SRS MLC 2POS PLUG HOUSING

Connector No: D5909A

Option: PREMIUM

Repair Kit Part Number: 68068651AA

Cavity Count: 2

Fig 1: Speaker-Right Front Door Connector End View (Premium)

Courtesy of CHRYSLER

Fig 2: Speaker-Right Front Door Component Location (Premium)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X208

GY/DG

AMPLIFIED RIGHT I/P SPEAKER (+)

N/A

X298

GY/LG

AMPLIFIED RIGHT I/P SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
