Speaker-Left Rear Door (D5910A)

Harness-Family: Door_Left_Rear

Color: WHITE

Gender: FEMALE

Part Number: 174921-1

Part Description: 070 SERIES MULTILOCK CONNECTOR PLUG HSG

Connector No: D5910A

Option: ~~

Repair Kit Part Number: 68040489AA

Cavity Count: 3

Fig 1: Speaker-Left Rear Door Connector End View

Courtesy of CHRYSLER

Fig 2: Speaker-Left Rear Door Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X205

GY/LG

LEFT REAR SPEAKER (+)

N/A

X295

GY/DG

LEFT REAR SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
