Solenoid-Variable Camshaft Timing (D2474)

Harness-Family: Mult_Displ_Solenoid

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6434-40

Part Description: 1.5 YESC FUEL INJ 2P ASSY DKEY INSL

Connector No: D2474

Option: Standard

Repair Kit Part Number: 68045333AA

Cavity Count: 2

Fig 1: Solenoid-Variable Camshaft Timing Connector End View

Courtesy of CHRYSLER

Fig 2: Solenoid-Variable Camshaft Timing Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z904

GROUND

N/A

Z903

0.50

GROUND

N/A

K442

VCT CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
