Solenoid-EVAP/Purge (Except 3.0L) (D21A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 1 928 403 874

Part Description: INSULATOR

Connector No: D21A

Option: EXCEPT 3.0L

Repair Kit Part Number: 05143779AA

Cavity Count: 2

Fig 1: Solenoid-EVAP/Purge Connector End View (Except 3.0L)

Courtesy of CHRYSLER

Fig 2: Solenoid-EVAP/Purge Component Location (Except 3.0L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K52

DB/WT

EVAP PURGE CONTROL

N/A

Z903

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
