Sensor-Oxygen 1/1 (3.0L Diesel) (D2397A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1 928 405 109

Part Description: Not Available

Connector No: D2397A

Option: 3.0L DIESEL

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Sensor-Oxygen 1/1 Connector End View (3.0L Diesel)

Courtesy of CHRYSLER

Fig 2: Sensor-Oxygen 1/1 Component Location (3.0L Diesel)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K89

BR/LG

O2 1/1 POSITIVE CURRENT CONTROL

N/A

K902

BR/DG

O2 RETURN (UPSTREAM)

N/A

K79

BR/LB

O2 1/1 HEATER CONTROL

N/A

F343

BR/YL

FUSED ASD RELAY OUTPUT

N/A

K41

DB/LB

O2 1/1 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
