Connector-Star Can C IP C2 (D2599B)

Harness-Family: IP

Color: NATURAL

Gender: FEMALE

Part Number: 2-1418639-1

Part Description: Not Available

Connector No: D2599B

Option: Standard

Repair Kit Part Number: 68137881AA

Cavity Count: 2

Fig 1: Connector-Star Can C Ip C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Connector-Star Can C Ip C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D11

YL/DB

CAN C (+)

N/A

D12

CAN C (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
