Connector-Star Can C IP C11 (D2599K)

Harness-Family: IP

Color: Natural

Gender: MALE

Part Number: 2-1418639-1

Part Description: Not Available

Connector No: D2599K

Option: ~~

Repair Kit Part Number: 68137881AA

Cavity Count: 2

Fig 1: Connector-Star Can C Ip C11 Connector End View

Courtesy of CHRYSLER

Fig 2: Connector-Star Can C Ip C11 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D77

CAN C (+) - PARK ASSIST MODULE

N/A

D78

CAN C (-) - PARK ASSIST MODULE

N/A

⁽¹⁾	Pins not listed are not used for this connector
