Connector-Star Can C Dash C9 (D2600J)

Harness-Family: HDLP_Dash

Color: Natural

Gender: MALE

Part Number: 2-1418639-1

Part Description: Not Available

Connector No: D2600J

Option: ~~

Repair Kit Part Number: 68137881AA

Cavity Count: 2

Fig 1: Connector-Star Can C Dash C9 Connector End View

Courtesy of CHRYSLER

Fig 2: Connector-Star Can C Dash C9 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D249

YL/GY

COM___CAN_C____DRIVER_ASSIST_MODULE__

N/A

D248

COM___CAN_C____DRIVER_ASSIST_MODULE__

N/A

⁽¹⁾	Pins not listed are not used for this connector
