Coil-Ignition 5 (3.6L) (D5208)

Harness-Family: Injector

Color: BLACK

Gender: FEMALE

Part Number: 1-1924067-1

Part Description: 1.2 STANDARD LATCH VERSION CONN W/O CPA

Connector No: D5208

Option: 36L

Repair Kit Part Number: 68137867AA

Cavity Count: 2

Fig 1: Coil-Ignition 5 Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 5 Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K16

DB/YL

COIL CONTROL 5

N/A

F344

BR/GY

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
