Coil-Ignition 2 (3.6L) (D5205)

Harness-Family: Injector

Color: BLACK

Gender: FEMALE

Part Number: 1-1924067-1

Part Description: 1.2 STANDARD LATCH VERSION CONN W/O CPA

Connector No: D5205

Option: 3.6L

Repair Kit Part Number: 68137867AA

Cavity Count: 2

Fig 1: Coil-Ignition 2 Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 2 Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K17

DB/TN

COIL CONTROL 2

N/A

F344

BR/GY

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
