Clutch-A/C Compressor (Acc) (3.6L) (D6655A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 7287-1596-30

Part Description: 2P 1.5 YESC RP SLD (FUEL INJECTOR)W/CPA

Connector No: D6655A

Option: 36L

Repair Kit Part Number: 68065018AA

Cavity Count: 2

Fig 1: Clutch-A/C Compressor (acc) Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Clutch-A/C Compressor (acc) Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

DB/OR

A/C CLUTCH CONTROL OUTPUT

N/A

Z909

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
