Amplifier-Radio C1 (Standard) (D3804A)

Harness-Family: Body

Color: WHITE

Gender: FEMALE

Part Number: 1438759-1

Part Description: 22 WAY HYBRID PLUG ASSEMBLY

Connector No: D3804A

Option: Standard

Repair Kit Part Number: 68032268AA

Cavity Count: 22

Fig 1: Amplifier-Radio C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Amplifier-Radio C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z924

GROUND

N/A

D207

WT/LG

CAN IHS (+)

N/A

X51

DG/DB

LEFT REAR SPEAKER (+)

N/A

X52

GY/DB

RIGHT REAR SPEAKER (+)

N/A

X53

DB/GY

RADIO LEFT FRONT AUDIO (+)

N/A

X54

GY/LB

RADIO RIGHT FRONT AUDIO (+)

N/A

X298

GY/LG

AMPLIFIED RIGHT I/P SPEAKER (-)

N/A

X299

GY/YL

AMPLIFIED LEFT I/P SPEAKER (-)

N/A

X303

DG/TN

AMPLIFIED LEFT REAR SPEAKER (+)

N/A

X200

GY/BR

AMPLIFIED CENTER I/P SPEAKER (+)

N/A

A931

FUSED B(+)

N/A

D206

CAN IHS (-)

N/A

X57

DG/OR

LEFT REAR SPEAKER (-)

N/A

X58

GY/OR

RIGHT REAR SPEAKER (-)

N/A

X55

DG/BR

RADIO LEFT FRONT AUDIO (-)

N/A

X56

GY/BR

RADIO RIGHT FRONT AUDIO (-)

N/A

X208

GY/DG

AMPLIFIED RIGHT I/P SPEAKER (+)

N/A

X209

GY/OR

AMPLIFIED LEFT I/P SPEAKER (+)

N/A

X393

DG/GY

AMPLIFIED LEFT REAR SPEAKER (-)

N/A

X290

GY/OR

AMPLIFIED CENTER I/P SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
