Airbag-Side Curtain-Right (D3084A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: PPI0001460

Part Description: SRS CONNECTOR AK2 FERRITE

Connector No: D3084A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Airbag-Side Curtain-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Airbag-Side Curtain-Right Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

OR/LB

RIGHT CURTAIN SQUIB 1 LINE 1

N/A

WT/LB

RIGHT CURTAIN SQUIB 1 LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
