Actuator-RECIRCULATION Door (RHD) (D10A)

Harness-Family: IP

Color: ~~

Gender: FEMALE

Part Number: 1456985-4

Part Description: Not Available

Connector No: D10A

Option: RHD

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Actuator-Recirculation Door Connector End View (RHD)

Courtesy of CHRYSLER

Fig 2: Actuator-Recirculation Door Component Location (RHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C68

RECIRCULATION DOOR COMMON DRIVER

N/A

C26

TN/OR

REFERENCE VOLTAGE SUPPLY

N/A

C333

TN/YL

SIGNAL GROUND

N/A

C333

TN/YL

SIGNAL GROUND

N/A

C26

TN/OR

REFERENCE VOLTAGE SUPPLY

N/A

C32

DB/TN

RECIRCULATION DOOR DRIVER

N/A

C268

DB/YL

RECIRCULATION DOOR DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
