Actuator-Blend Door-Right (D54A)

Harness-Family: IP

Color: ~~

Gender: MALE

Part Number: 1456985-4

Part Description: Not Available

Connector No: D54A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Actuator-Blend Door-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Actuator-Blend Door-Right Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C52

DB/LG

RIGHT BLEND DOOR COMMON DRIVER

N/A

C131

SENSOR GROUND

N/A

C24

OR/LB

RIGHT BLEND DOOR FEED

N/A

C224

OR/TN

RIGHT BLEND DOOR SIGNAL

N/A

C252

LG/DB

RIGHT BLEND DOOR DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
