Seat Belt-Retractor TENSIONER-Passenger (D6676A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: PPI0001460

Part Description: SRS CONNECTOR AK2 FERRITE

Connector No: D6676A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Seat Belt-Retractor Tensioner-Passenger Connector End View

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner-Passenger Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R506

LB/DG

PASSENAGER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

R504

PASSENAGER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
