Seat Belt-Retractor TENSIONER-Driver (D6673A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: PPI0001460

Part Description: SRS CONNECTOR AK2 FERRITE

Connector No: D6673A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Seat Belt-Retractor Tensioner-Driver Connector End View

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner-Driver Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R505

LG/DG

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

R503

DRIVER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
