Lamp-Door Handle-Passenger (LHD) (D2615A)

Harness-Family: Door_Pass_2

Color: BLACK

Gender: MALE

Part Number: ~~

Part Description: Not Available

Connector No: D2615A

Option: LHD

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Door Handle-Passenger Connector End View (LHD)

Courtesy of CHRYSLER

Fig 2: Lamp-Door Handle-Passenger Component Location (LHD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

M35

0.35

DOOR AMBIENT LAMP FEED PASS

N/A

M36

PASS DR LGHTNG RTN

N/A

M36

0.35

PASS DR LGHTNG RTN

N/A

M35

DOOR AMBIENT LAMP FEED PASS

N/A

⁽¹⁾	Pins not listed are not used for this connector
