Heater-Seat Cushion-Right C1 (D6662A)

Harness-Family: Seat_Heater_RT

Color: BLACK

Gender: MALE

Part Number: ~~

Part Description: Not Available

Connector No: D6662A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Heater-Seat Cushion-Right C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Heater-Seat Cushion-Right C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P188

RIGHT FRONT SEAT HEATER CONTROL

N/A

Z919

GROUND

N/A

P688

TN/DB

RIGHT FRONT HEATED SEAT TEMP SENSE

N/A

P968

BK/RD

HEATED SEAT SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
