Heater-Seat Cushion-Left Rear (D2401A)

Harness-Family: LT_RR_CUSHION

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: D2401A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Heater-Seat Cushion-Left Rear Connector End View

Courtesy of CHRYSLER

Fig 2: Heater-Seat Cushion-Left Rear Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P177

LEFT REAR SEAT HEATER CONTROL

N/A

P672

BK/RD

LEFT REAR HEATED SEAT TEMP SENSE

N/A

P968

BK/RD

HEATED SEAT SENSOR RETURN

N/A

Z923

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
