Solenoid-Camshaft 2/1 Position (3.6L) (D2484A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: F495100

Part Description: Not Available

Connector No: D2484A

Option: 3.6L

Repair Kit Part Number: 68149290AA

Cavity Count: 2

Fig 1: Solenoid-Camshaft 2/1 Position Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Solenoid-Camshaft 2/1 Position Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K78

VVT INTAKE CONTROL 2

N/A

Z903

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
