Body - Interior & Exterior: DECKLID/Hatch/Liftgate/Tailgate: Hinge: Removal: Removal

Fig 1: Liftgate Harness

Courtesy of CHRYSLER GROUP, LLC

NOTE:

It is not necessary to remove the liftgate to replace one or both hinges. The hinges can be replaced one at a time.

NOTE:

A suitable body sealant should be used when removing or moving the hinges.

Support liftgate on a suitable lifting device.
Disconnect liftgate harness and washer hose.

Fig 2: Liftgate Hinge Bolts
Courtesy of CHRYSLER GROUP, LLC
Using a grease pencil or equivalent, mark the location of the hinge to aid installation.
Remove the two bolts that secure the liftgate hinge (1) to the liftgate.

Fig 3: Liftgate Hinge Nuts & Fastener
Courtesy of CHRYSLER GROUP, LLC
Carefully, move down headliner and remove two nuts and one fastener. Remove hinge from vehicle.
