Differential Coil - Removal

REMOVAL

Special Tools:










1. Remove differential case from axle housing.
2. Remove bearing from the coil side of the differential case with Puller (1), Plug (2), and Adapters (3).





3. Remove thrust washer (1) from differential case and coil (2).





4. Remove coil (1) from differential case.
