Front Half Door Lock Cylinder - Removal
REMOVAL
1. Remove the latch (5), Front Door Latch - Removal.
NOTE: Full door shown, half door similar.
2. Remove the clip (3) and separate the lock cylinder (2) and gasket (1) from the door.
REMOVAL
1. Remove the latch (5), Front Door Latch - Removal.
NOTE: Full door shown, half door similar.
2. Remove the clip (3) and separate the lock cylinder (2) and gasket (1) from the door.
