PROP, Gas: Removal: Removal
| 1 - RETAINING CLIP |
| 2 - BALL SOCKET |
| 3 - BALL STUD |
NOTE:
The support cylinders can be replaced one at a time.
- Open and support the hood.NOTE: Lift the clips only enough to release the ball studs.Fig 2: Using Small Flat Bladed Tool To Release Upper Retaining Clips While Pulling Ball Socket Away From Ball Stud
Courtesy of CHRYSLER LLC
1 - BALL SOCKET 2 - RETAINING CLIP 3 - FLAT BLADED TOOL 4 - BALL STUD - Using a small flat bladed tool, or equivalent, release the upper retaining clips while pulling the ball socket away from the ball stud.
CAUTION: Do not pull the supports from the middle while removing.
- Pulling at the ends only, remove the support cylinder.
