Door - Half Rear: Hinge: Removal: Hinge

Fig 1: View Of Door

Courtesy of CHRYSLER LLC

NOTE: A suitable body sealant should be used when removing or moving the hinges.

Remove the door (2). See REMOVAL .

Fig 2: Body Hinge
Courtesy of CHRYSLER LLC
Using a grease pencil or equivalent, mark the body hinge (1) and (4) location and remove the bolts (2) and (3).

Fig 3: Identifying Door Hinge
Courtesy of CHRYSLER LLC
Using a grease pencil or equivalent, mark the door hinge (2) and (3) location and remove the bolts (1) and (4).
