Release-Hood Latch: Removal

Fig 1: Remove/Install Nuts At Radiator Crossmember
GC0044947Courtesy of DAIMLERCHRYSLER CORP.
  1. Remove the hood latch (4) (Refer to BODY/HOOD/LATCH - REMOVAL) .
  2. Remove release cable (2) from the three hood release cable retainers (1).
    Fig 2: Remove/Install Release Hood Handle Assembly
    GC0044948Courtesy of DAIMLERCHRYSLER CORP.
  3. From inside the vehicle, remove the two screws (3) that secure the hood release handle (1) to the cowl trim panel.
  4. Remove the grommet (2) from the cowl panel (1) and remove the hood release cable and handle assembly (4).
