Installation - CAC Inlet Hose

WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install charge air cooler (CAC) inlet hose on turbocharger and CAC. See Figure.
  2. Tighten hose clamps. See Figure.
  3. Close hood.
