Section 592 (Audio System & Video System (Service Information)): Antenna-Satellite: Description

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Satellite Antenna

Courtesy of DAIMLERCHRYSLER CORP.

The satellite radio antenna is secured by a threaded fastener and two retainers which protrude through a hole in the roof panel. Two wires from the antenna are connected to the satellite receiver module.
