Zener Diode 1 Connector End View

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
DIODE-ZENER NO. 1 - 2 WAY

GCWK580118Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 Z387 18BK GROUND
2 A15 16RD/TN FUSED ASD RELAY OUTPUT
