Wiring Trailer Tow Terminal Connector End View

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
WIRING-TRAILER TOW TERMINAL - 1 WAY

GCWK580418Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 B400 14DG TRAILER TOW ELECTRIC BRAKE OUTPUT
