Shield Radio (Satellite Radio) Connector End View (C2)

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

RADIO C2 SHIELD (SATELLITE RADIO) - 1 WAY

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
1	X917 18DG	AUDIO SIGNAL COMMON
