Shield Radio (Hands Free) Connector End View (C1)

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

RADIO C1 SHIELD (HANDS FREE) - 1 WAY

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
1	X795 18DG	COMMON AUDIO OUTPUT
