Section 588 (Connector End Views)
>>
Connector Pin-Outs
>>
Satellite Radio Receiver Connector End View
Satellite Radio Receiver Connector End View
WARNING:
This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
RECEIVER-SATELLITE RADIO - 1 WAY
Courtesy of DAIMLERCHRYSLER CORP.
CAV
CIRCUIT
FUNCTION
1
X917 18NA
AUDIO SIGNAL COMMON
