Passenger Door Unlock Relay Connector End View

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

RELAY-DOOR UNLOCK-PASSENGER

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
-	P792	DOOR UNLOCK RELAY OUTPUT
-	P292	DOOR UNLOCK RELAY CONTROL
-	A905	FUSED B(+)
-	A213	FUSED B(+)
-	Z387	GROUND
