Door Lock Relay Connector End View

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

RELAY-DOOR LOCK

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
-	P778	DOOR LOCK RELAY OUTPUT
-	P777	DOOR LOCK RELAY CONTROL
-	A905	FUSED B(+)
-	A213	FUSED B(+)
-	Z387	GROUND
