5.7L Engine

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: 5.7L Thermostat

Courtesy of DAIMLERCHRYSLER CORP.

1 - THERMOSTAT HOUSING

4 - BOLT

WARNING: DO NOT LOOSEN THE RADIATOR DRAINCOCK WITH THE COOLING SYSTEM HOT AND PRESSURIZED. SERIOUS BURNS FROM THE COOLANT CAN OCCUR.

Do not waste reusable coolant. If the solution is clean, drain the coolant into a clean container for reuse.

If the thermostat is being replaced, be sure that the replacement is the specified thermostat for the vehicle model and engine type.

Disconnect the negative battery cable.
Drain the cooling system
Remove the radiator hose clamp and radiator hose at the thermostat housing (1).
Remove the thermostat housing mounting bolts (2), thermostat housing (1) and thermostat.
