5.7L Engine
WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
| 1 - THERMOSTAT HOUSING |
| 4 - BOLT |
- Position the thermostat and housing (1) on the front cover.
- Install thermostat housing bolts (2). Tighten the bolts (2) to 13 N.m (112 in. lbs.).
- Install the radiator hose onto the thermostat housing (1).
- Fill the cooling system (Refer to COOLING - STANDARD PROCEDURE) .
- Connect negative battery cable.
- Start and warm the engine. Check for leaks.
