Pressure Line - Fan To Pump
WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
- Siphon the power steering fluid from the reservoir.
- Remove the pressure line at the pump.
- Raise and support the vehicle.
- Remove the front skid plate.
- Disconnect the electrical connector (6) for the pressure switch (1).
- Remove the quick connect pressure line (5) from the hydraulic cooling fan filter (2) using special tool 8875-A (3).
- Remove the pressure line (5) from the vehicle.
- Remove the pressure switch (1) if necessary.
