Jounce Bumper: Installation
WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
- Install the jounce bumper, Tighten to 54 N.m (40 ft. lbs.).
- Install the upper isolator.
1 - LOWER ISOLATOR 2 - SPRING LOCATOR 3 - COIL SPRING - Install the lower isolator (1).
- Pull down on the axle and position the coil spring in the lower isolator.
- Raise the axle with the hydraulic jack.
- Install the shock absorber to the axle bracket and tighten to 115 N.m (85 ft. lbs.).
- Install the stabilizer bar link to the body rail, Tighten to 102 N.m (75 ft. lbs.).
- Install the wheel and tire assemblies.
- Remove the supports and lower the vehicle.
