Lamp - Export
WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
- Position the license plate lamp unit onto the back of the license plate bracket. See Figure.
- Install and tighten the two screws that secure the lamp unit to the back of the license plate bracket. Tighten the screws to 2 N.m (20 in. lbs.).
- Reinstall the bulb and socket into the lamp unit. (Refer to ELECTRICAL/LAMPS/LIGHTING - EXTERIOR/LICENSE PLATE LAMP BULB - INSTALLATION - REST-OF-WORLD) .
- Reconnect the battery negative cable.
