Automatic Transmission:

WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the transmission mount to transmission. See Fig 1 and Fig 2. Install the bolts.
    Fig 1: TRANSMISSION MOUNT - 3.7L 2WD AUTO TRANS
    GC0026081Courtesy of DAIMLERCHRYSLER CORP.
    1 - BOLT
    2 - MOUNT
    Fig 2: TRANSMISSION MOUNT - 3.7L 4WD AUTO TRANS
    GC0026082Courtesy of DAIMLERCHRYSLER CORP.
    1 - MOUNT
    2 - BOLT
  2. Position the crossmember in the vehicle. Install the crossmember to mount through bolt and nut.
  3. Remove the transmission support.
  4. Lower the vehicle.
  5. Connect negative cable to battery.
