Defroster Duct: Removal

WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: On vehicles equipped with airbags, disable the airbag system before attempting any steering wheel, steering column, or instrument panel component diagnosis or service. Disconnect and isolate the battery negative (ground) cable, then wait two minutes for the airbag system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to take the proper precautions could result in an accidental airbag deployment and possible personal injury or death.

Remove the instrument panel (Refer to INSTRUMENT CLUSTER - REMOVAL).
Remove the three screws that secure the defroster duct to the instrument panel. See Fig 1.
Remove the defroster duct from the instrument panel.

Fig 1: Defroster Duct

Courtesy of DAIMLERCHRYSLER CORP.

1 - INSTRUMENT PANEL

2 - DEFROSTER DUCT

3 - SCREW (3)
