Passenger Seat Belt Switch Shorted to Battery

Test 1:

SYMPTOM
PASSENGER SEAT BELT SWITCH SHORT TO BATTERY

TEST NOTE
This symptom is diagnosed using the test PASSENGER SEAT BELT SWITCH CIRCUIT TEST.


WHEN MONITORED
The ACM monitors the Seat Belt Buckle Switch circuit for an short to battery.

SET CONDITION
The code will set if the ACM detects high circuit voltage.

POSSIBLE CAUSES
- ACM, Passenger seat belt switch DTC
