Courtesy Lamps Inoperative From Dome Lamp Switch Only

Test 1 - 3:






SYMPTOM
COURTESY LAMPS INOPERATIVE FROM DOME LAMP SWITCH ONLY

POSSIBLE CAUSES
- DTC present
- Left multi function switch dimmer open
- BCM dimmer inoperative
