BCM Messages Not Received By MIC

Test 1:

SYMPTOM
BCM MESSAGES NOT RECEIVED BY MIC

WHEN MONITORED
Monitored during ignition on.

SET CONDITION
No BCM messages received for 6 seconds.

POSSIBLE CAUSES
- No response - PCI bus - BCM
- Intermittent condition
- Instrument cluster
