Wiring Diagrams

8w-63-2 (LHD Midline/Premium):

8w-63-3 (Premium I/III):

8w-63-4 (Midline/Premium):

8w-63-5 (Premium II/III):

8w-63-6 (LHD Premium I/III):

8w-63-7 (RHD Premium I/III):

8w-63-8 (Premium II/III):

8w-63-9 (Premium II/III):

8w-63-10 (LHD Midline/Premium):

8w-63-11 (RHD Midline/Premium):

8w-63-12 (Premium I/III):

NOTE: To view sheets referred to in these diagrams, see Complete Body and Chassis Diagrams. Electrical Diagrams
